Get Super-Accurate Inside and Outside Measurements the Easy Way

Bar Gauges Deliver Can’t Miss Measurements. Rulers and tape measures have their limitations, especially when it comes to inside measurements. That’s why bar gauges have been used to nail this common task for generations. Woodworkers cobble together a couple sticks, but they were often clumsy to use and less than reliable.

Grouped product items
Product Image Product Name
Modular Bar Gauge System with Trammel Head Set in Systainer Case Modular Bar Gauge System with Trammel Head Set in Systainer Case SKU: MBGTS-SYS-18
The Modular Bar Gauge System in a Systainer Case includes (8) tips (2) clamp bodies and the bars necessary to cover a range from 8-1/4" to 96-5/8". Also includes Trammel Head Set Accessory. All items are nestled in a foam lined Systainer style carrying case.
Out of stock

$329.99
Modular Bar Gauge System in Systainer Case Modular Bar Gauge System in Systainer Case SKU: MBG-SYS-18
The Modular Bar Gauge System in a Systainer Case includes (8) tips (2) clamp bodies and the bars necessary to cover a range from 8-1/4" to 96-5/8". All items are nestled in a foam lined Systainer style carrying case.
Out of stock

$289.99
Modular Bar Gauge System with Trammel Head Set in WP Case Modular Bar Gauge System with Trammel Head Set in WP Case SKU: MBGTS-WP-18
The Modular Bar Gauge System in a Woodpeckers Case includes (8) tips (2) clamp bodies and the bars necessary to cover a range from 8-1/4" to 96-5/8". Also includes Trammel Head Set Accessory. All items are nestled in a foam lined Woodpeckers carrying case.
Out of stock

$289.99
Modular Bar Gauge System in WP Case Modular Bar Gauge System in WP Case SKU: MBG-WP-18
The Modular Bar Gauge System in a Woodpeckers Case includes (8) tips (2) clamp bodies and the bars necessary to cover a range from 8-1/4" to 96-5/8". All items are nestled in a foam lined Woodpeckers carrying case.
Out of stock

$249.99
Trammel Head Set Accessory Trammel Head Set Accessory SKU: TRMHD-SET-18
Includes (2) trammel heads, (2) carbide tipped scribes and (2) pencils. This Bar Gauge Accessory is compatible with 3/8" diameter wood dowel rods or the bars included with the Modular Bar Gauge System
Out of stock

$49.99
Bar Gauge bodies (pair) Bar Gauge bodies (pair) SKU: BGBODIES-18
One pair of bodies including knobs and screw. Perfect for building your own modular bar gauge.
Out of stock

$49.99
Bar Starter Set - 12 Bar Starter Set - 12" RANGE SKU: BGBARS-12-18
One pair bars. (Brass tips and bodies sold separately). This pair of bars is the starter set necessary to build your own modular system. Covers a measurement range from 8-1/4" to 14-7/8" with tips attached.
Out of stock

$29.99
Mushroom Bar Gauge tips (pair) Mushroom Bar Gauge tips (pair) SKU: BGTIPS-MR-18
Solid brass tips for Modular Bar Gauge System. 1/4-20 male thread.
Out of stock

$19.99
6 6" Length Bar Extension SKU: BGBAR-EXT6-18
The 6" Bar Extension can be attached to any bar. Adds 6" to measurement range.
Out of stock

$15.99
12 12" Length Bar Extension SKU: BGBARS-EXT-18
The 12" Bar Extension can be attached to any bar. Adds 12" to measurement range.
Out of stock

$15.99
Arrow Bar Gauge tips (pair) Arrow Bar Gauge tips (pair) SKU: BGTIPS-ARROW-18
Solid brass tips for Modular Bar Gauge System. 1/4-20 male thread.
Out of stock

$14.99
Blunt Bar Gauge tips (pair) Blunt Bar Gauge tips (pair) SKU: BGTIPS-BLUNT-18
Solid brass tips for Modular Bar Gauge System. 1/4-20 male thread.
Out of stock

$14.99
Pin Bar Gauge tips (pair) Pin Bar Gauge tips (pair) SKU: BGTIPS-PIN-18
Solid brass tips for Modular Bar Gauge System. 1/4-20 male thread.
Out of stock

$14.99
Replacement Carbide Tipped Scribe Replacement Carbide Tipped Scribe SKU: SCRIBE-TIP-18
Replacement scribe tips for Trammel Head Kit. ,
Out of stock

$2.99

Woodpeckers latest OneTIME Tool, the Modular Bar Gauge System, is not only the ultimate inside measurement tool, but new “Mushroom-style” tips make it a dead-on outside measurement tool! These new tips and new, modular style connecting rods allow measurements from as little as 8-1/4" all the way up to 96-5/8".

Why These Bar Gauges Rule. Our new Bar Gauge System excels when measuring inside dimensions in a variety of conditions thanks to innovative, interchangeable, solid brass tips that thread into the ends of the sturdy, 3/8" stainless steel rods.

The blunt-end tips are perfect for gauging the distance between cabinet parts for shelves, door and drawer openings and more. When making built-ins, they are indispensable taking measurements between walls. And they have dozens more uses.

Attach arrow-shaped tips to check if a cabinet, frame or drawer box is square by comparing the distance between diagonal corners.

Use the pin tips to measure the distance between cabinet parts like drawer sides to find the exact measurement for drawer bottoms, or other cabinet parts that nest in dados, rabbets or grooves.

Now the Best Part– DOUBLE YOUR ACCURACY! That’s right, double your accuracy. Imagine you’ve set your Bar Gauge and found the perfect measurement. With the bars locked, you go straight to your table saw and use the Bar Gauge to set the fence, or set a stop block at your chop saw. The Bar Gauge gives you the exact physical reference for super-accurate, repeatable cuts every time.

The Magic of New “Mushroom-Style” Tips. This style tip adds a whole new dimension to the versatility of our new Bar Gauges. Use the flanged ends to take outside dimensions. What’s the big deal, you say? OK, the 3/4" mushroom “stem” is the precise length of the other style tips when threaded into the bars. By simply switching tips, you can now transfer that perfect outside dimension to set up your table or miter saw to replicate an inside dimension. (Note: If you already own our Bar Gauge, Mushroom tips can be ordered separately).

Optional Trammel Head Set. This accessory is perfect for those needing to draw large arcs on sheet goods. It consists of (2) trammel heads that can be locked anywhere along the rods length. Each head can hold a pencil and a carbide tipped scribe. Use the scribe as a pivot or to scratch a permanent mark.

The Modular Bar Gauge System comes in two different set configurations. One with and one without the new Trammel Head Set Accessory. Each set includes all eight tips; two end bars; six, 12” long extension bars; two, 6” long extension bars and two, rod clamp bodies with knurled knobs. The Modular Bar Gauge System comes in a molded, protective case with a custom cut foam interior. Alternatively, the system is also available in a Systainer style case.

This Modular Bar Gauge System is part of Woodpeckers OneTIME Tool program and is only made to order. Deadline to order yours is Monday, May 21, 2018. Once the deadline passes and orders are filled, these tools will be retired from our product line. Delivery is scheduled for September, 2018.

Like all Woodpeckers tools, the Bar Gauge System is machined in our shop in Strongsville, Ohio.
