Woodsmith Sliding Hold-Down Plan

SKU
WOODSMITH-SLIDING-HOLD-DOWN-GROUP

When ripping narrow strips or cutting a rabbet along the edge of a workpiece, it’s sometimes hard to keep the board flat against the saw table. And if you use a featherboard, it can get in the way. The handy sliding hold-down jig you see here solves these problems. Keith Krueger of Bellefontaine, Ohio, sent us the prototype for this jig, and I’ll admit it’s a clever idea. What’s really unique is how the featherboard actually slides with the workpiece at the end of the cut, maintaining pressure on the workpiece. The secret to this is in the drawer slides hidden inside. And the photo at left shows how the featherboard carriage is held stationary with a pivoting catch until the push block releases it. Then the top of the carriage (and the featherboard) moves with the workpiece through the cut.

We offer the Woodsmith Sliding Hold-Down plan as a downloadable PDF or a printed format that we ship to you.

Grouped product items
Product Image Product Name Price
Woodsmith Sliding Hold-Down Standard Plan – 8.5” x 11” PDF Download Woodsmith Sliding Hold-Down Standard Plan – 8.5” x 11” PDF Download SKU: SN09636PL
Plans will be emailed to you, please allow approximately 1 hour for processing. Phone orders cannot be accepted.

Add to Wish List Add to Compare
$12.95
Woodsmith Sliding Hold-Down Standard Plan – 8.5” x 11” Print (Shipped to You) Woodsmith Sliding Hold-Down Standard Plan – 8.5” x 11” Print (Shipped to You) SKU: SN09636PLPR

Add to Wish List Add to Compare
$18.35

Cutting narrow or thin stock can be a challenge. This clever jig makes it easier and safer.

Step-by-step instructions, exploded views, materials list, and more—these plans have everything you need to build your own Sliding Hold-Down.

What you get (Downloadable PDFs):

Standard Plan:

  • 8.5” x 11” PDF of 6 printable (digital) pages of step-by-step instructions
  • 20 full-color photos illustrations and exploded views
  • Shop-tested tips for using the jig
  • Materials list
  • Retail sources for hardware and supplies



What you get (Printed & Shipped):

Standard Plan:

  • 6 pages of step-by-step instructions
  • 20 full-color photos illustrations and exploded views
  • Shop-tested tips for using the jig
  • Materials list
  • Retail sources for hardware and supplies
  • 8.5” x 11” print shipped to you
