Woodsmith Aluminum Squares Plan

SKU
WOODSMITH-ALUMINUM-SQUARES-GROUP

A good square is one tool that’s indispensable in the shop. I use it on just about every project I build. But some squares aren’t all that accurate. That’s why I like the design of the squares. Not only can you customize them to your liking, but they’re adjustable. If they should ever lose their accuracy, there’s an easy fix. Four cap screws hold the blade securely to the handle of the square. If the blade ever gets knocked out of square, you can loosen the screws, adjust it back to 90°, and then retighten the screws. The really nice thing about these squares is they’re easy to build with common shop tools. In a nutshell, you’ll take readily available aluminum bar stock and laminate it to form the handle, as shown at left. Finally, after attaching the blade and adjusting it, you’re ready to put the square to use in your shop.

We offer the Woodsmith Aluminum Squares plan as a downloadable PDF or a printed format that we ship to you.

Grouped product items
Product Image Product Name Price
Woodsmith Aluminum Squares Standard Plan – 8.5” x 11” PDF Download Woodsmith Aluminum Squares Standard Plan – 8.5” x 11” PDF Download SKU: SN09136PL
Plans will be emailed to you, please allow approximately 1 hour for processing. Phone orders cannot be accepted.

Add to Wish List Add to Compare
$9.95
Woodsmith Aluminum Squares Standard Plan – 8.5” x 11” Print (Shipped to You) Woodsmith Aluminum Squares Standard Plan – 8.5” x 11” Print (Shipped to You) SKU: SN09136PLPR

Add to Wish List Add to Compare
$21.95

Build your own precision layout tool. All it takes are a few pieces of aluminum and a little time at the table saw and drill press.

Step-by-step instructions, exploded views, materials list, and more—these plans have everything you need to build your own Aluminum Squares.

What you get (Downloadable PDFs):

Standard Plan:

  • 8.5” x 11” PDF of 9 printable (digital) pages of step-by-step instructions
  • 76 full-color photos, illustrations, and exploded views
  • Shop-tested tips & techniques
  • Cutting diagrams. Materials list. Project sources


What you get (Printed & Shipped):

Standard Plan:

  • 9 pages of step-by-step instructions
  • 76 full-color photos, illustrations, and exploded views
  • Shop-tested tips & techniques
  • Cutting diagrams. Materials list. Project sources
  • 8.5” x 11” print shipped to you
