Carbide Headed Compact Shallow Pattern Bits, 3-Flute, 1/4" Shank

SKU
ULTRA-SHEAR-COMPACT-SHALLOW-PATTERN-14-BITS-GROUP

Ultra-Shear borrowed a technique from metal-working tool companies to bring you short cut length pattern bits unlike any others on the market. Solid carbide spiral bits typically have cutting diameters that match their shank.  A cutting diameter larger than the shank involves grinding away immense amounts of carbide to create the shank. That's why most router bits have carbide edges brazed to a steel body. But that eliminates the cutting geometry and concentricity advantages of solid carbide spirals. Our new Hybrid bits marry a solid carbide spiral cutting head with an economical steel shaft. This opens up a world of opportunities for unique, high-performance designs while keeping prices competitive. The first of our Hybrid bits is a group of short cut length pattern bits. You may know them as "dado clean-out" bits, but that name doesn't begin to cover all the jobs these bits can tackle.

Choose $50 or more Mix and Match Ultra-Shear Bits, get FREE SHIPPING!
(Offer applies to Ultra-Shear Router Bits only - shipped to US).



Grouped product items
Product Image Product Name Price
Ultra-Shear 3-Flute Compact Shallow Pattern Router Bit 4-PC Set, Carbide Headed, 1/4" Shank, 1/2" Diameter Ultra-Shear 3-Flute Compact Shallow Pattern Router Bit 4-PC Set, Carbide Headed, 1/4" Shank, 1/2" Diameter SKU: US4PCCSP

free shipping info


Add to Wish List Add to Compare
Special Price $109.99 Regular Price $123.05
Ultra-Shear 3-Flute Compact Shallow Pattern Router Bit, Carbide Headed, 1/4" Shank, 1/2" Diameter, 3/8" Cutting Length, 1-13/16" Overall Length Ultra-Shear 3-Flute Compact Shallow Pattern Router Bit, Carbide Headed, 1/4" Shank, 1/2" Diameter, 3/8" Cutting Length, 1-13/16" Overall Length SKU: US2375CSP

free shipping info


Add to Wish List Add to Compare
Special Price $31.99 Regular Price $33.78
Ultra-Shear 3-Flute Compact Shallow Pattern Router Bit, Carbide Headed, 1/4" Shank, 1/2" Diameter, 5/16" Cutting Length, 1-13/16" Overall Length Ultra-Shear 3-Flute Compact Shallow Pattern Router Bit, Carbide Headed, 1/4" Shank, 1/2" Diameter, 5/16" Cutting Length, 1-13/16" Overall Length SKU: US2313CSP

free shipping info


Add to Wish List Add to Compare
Special Price $29.99 Regular Price $30.96
Ultra-Shear 3-Flute Compact Shallow Pattern Router Bit, Carbide Headed, 1/4" Shank, 1/2" Diameter, 1/4" Cutting Length, 1-13/16" Overall Length Ultra-Shear 3-Flute Compact Shallow Pattern Router Bit, Carbide Headed, 1/4" Shank, 1/2" Diameter, 1/4" Cutting Length, 1-13/16" Overall Length SKU: US2250CSP

free shipping info


Add to Wish List Add to Compare
Special Price $27.99 Regular Price $29.54
Ultra-Shear 3-Flute Compact Shallow Pattern Router Bit, Carbide Headed, 1/4" Shank, 1/2" Diameter, 3/16" Cutting Length, 1-13/16" Overall Length Ultra-Shear 3-Flute Compact Shallow Pattern Router Bit, Carbide Headed, 1/4" Shank, 1/2" Diameter, 3/16" Cutting Length, 1-13/16" Overall Length SKU: US2188CSP

free shipping info


Add to Wish List Add to Compare
Special Price $26.99 Regular Price $28.77

American Made Quality at Factory Direct Pricing

Whether you're trying to clean up a ragged surface or your dado wasn't quite deep enough, Ultra-Shear Hybrid Shallow Pattern Bits machine the bottom of a dado without affecting the width.  Just ride the bearing against the sides with the depth of cut set where you need it. You'll get a smooth bottom surface that will enhance your exposed joinery.  With depth of cut starting at just 3/16" and a close fit between the bearing and the cutter, you can clean up even the shallowest of dadoes.

You can face a similar problem with holes from a Forstner bit. The center spur cuts much deeper than the rest of the bit. You can eliminate the unsightly center spur mark with these Shallow Pattern Bits. Just ride the bearing around the perimeter, cutting deeper, but never changing the diameter.

These bits also excel at hinge mortising and other template routing chores. Unlike most of the pattern bits on the market, your template doesn't have to be extra thick to give you the shallow depth of cut you need for standard hinges.

We make the Shallow Pattern Bits in cut lengths of 3/16", 1/4", 5/16" and 3/8". Pick just the ones you need or save some money with the complete set. Like all Woodpeckers products, Ultra-Shear Compact Shallow Pattern Bits are made right here in our Strongsville, Ohio, facility just south of Cleveland, and sold direct.  The days of paying extra for middle-man markups are over. Buy directly from the manufacturer and pocket the savings. We’re confident you won’t find an American-made bit of similar design for less.



More Information
Country of Manufacture United States
Shank 1/4"
